Preseem Fiber Support

Supported manufacturers and models for Fiber OLT support

Supported OLTs

The following OLT product lines are supported by Preseem.  The following sections provide additional details and caveats for each product line.

  • Adtran SDX 6000 Series
  • Adtran TA5000 Series
  • BDCOM
  • Calix E3-2 and E7-2
  • Ubiquiti GPON and XGS-PON




Adtran SDX 6000 Series

Supported OLT Models

The Adtran SDX 6000 series is fully supported by Preseem.  This includes the following models:

  • SDX 6010-16
  • SDX 6020-48
  • SDX 6310-4
  • SDX 6312-4
  • SDX 6320-16
  • SDX 6324-4
  • SDX 6330-48




Adtran TA5000 Series

Supported OLT Models

The Adtran TA5000 series is fully supported by Preseem.  This includes the following models:

  • TA5000
  • TA5004
  • TA5006

Caveats

  • If Ubiquiti ONTs are used with Adtran TA5000 OLTs, the resulting interface counters are not reliable.  Preseem will not report on the polled throughput for these ONTs.




BDCOM

Supported OLT Models

The following BDCOM OLTs are supported by Preseem:

  • P3600-16E
  • P3608B
  • P3608-2TE
  • P3616-2TE

Chassis OLTs are not supported; please let us know if you need support for a BDCOM Chassis OLT.

Caveats

  • In rare cases, the OLT shows a value of 0.0 for the received power level of some ONTs at the OLT.  In these cases, Preseem will show an null / empty value for these ONTs.




Calix E3-2 and E7-2

Supported OLT Models

Preseem supports the E3-2 and E7-2 systems, running either EXA or AXOS firmware.




Ubiquiti GPON / XGS-PON

Supported OLT Models

The following Ubiquiti OLTs are supported by Preseem:

  • UFiber OLT
  • UFiber OLT4
  • UISP Fiber OLT XGS

Caveats

  • Ubiquiti OLTs do not expose the transmit power from the OLT, or the receive power at the OLT side of the fiber link.  Therefore, Preseem will show a null/empty value for these metrics.
      OLT Optics ONT Optics
    Tx Power No Yes
    Rx Power No Yes
