VLAN Configuration

How do I configure Preseem to inspect into 802.1q and 802.1ad VLANs?

By default, Preseem does not inspect into VLANs for either 802.1q or 802.1ad. This means that traffic in VLANs is simply bridged through Preseem without inspecting it (calculating its metrics) or shaping its bandwidth.

If you wish to inspect and shape VLAN traffic, there are two options:

1. Configure Preseem to inspect into any 802.1q or 802.1ad VLAN
2. Configure specific VLANs to inspect

Limitations

At present, Preseem can process 802.1ad (Q-in-Q) up to two VLANs deep.

Applying Configuration Changes

To apply the configuration below, the NetdevManager service needs to be restarted.

systemctl restart preseem-netdev-manager

Inspecting All VLAN Traffic

Note that Preseem version >= 1.10.5 is required to inspect all VLAN traffic.

Inspection (and shaping) of VLAN traffic is configured on a per-bridge basis in /etc/preseem/config.yaml. The following configuration snippet configures Preseem to inspect any VLANs on br0, for both 802.1q and 802.1ad:

bridges:
  br0:
    802.1q:
      InspectAllVlansByDefault: true
    802.1ad:
      InspectAllVlansByDefault: true

Inspecting Specific VLANs

The list of VLANs to inspect is configured on a per-bridge basis. The following example configures br1 to inspect traffic only for specific 802.1q and 802.1ad VLANs:

bridges:
  br1:
    802.1q:
      vlans:
        20:
          inspect: true
    802.1ad:
      stags:
        4050:
          ctags:
            99:
              inspect: true

Ignoring Specific VLANs

It is also possible to reverse the logic to inspect all VLANs by default, while ignoring specific VLANs:

bridges:
  br1:
    802.1q:
      inspectAllVlansByDefault: true
      vlans:
        20:
          inspect: false
    802.1ad:
      inspectAllVlansByDefault: true
      stags:
        4050:
        ctags:
          99:
            inspect: false
